Power/Low Voltage Types
Power/High Voltage Feedthroughs
500V feedthroughs are very small and so ideal when space is limited. 1KV feedthroughs are for general purpose instrumentation use.
These feedthroughs rated at up to 5KV and up to 20A come as single pin weldables with up to 4 pins on a 16CF or 16KF flange. Custom arrangements available on a choice of flange on request. There are also 5KV and 10KV feedthroughs up to 30A. These have up to 12 pins on a 40CF or 40KF flange.
Power Feedthroughs on CF, KF flanges with Kovar, SS, Ni and Cu conductors up to 5kV 20Amps:
221-005OCT1KV-8-BP
MULTIPIN ‘OCTAL’ FEEDTHROUGH, 8-WAY, 1” BASEPLATE, HV & AIR SIDE OCTAL CONNECTORS
261-08MO500
WELDABLE POWER FEEDTHROUGH, MOLYBDENUM CONDUCTOR, 1 PIN, 500V DC, 8 AMPS
261-1000CU3K-C40
DN40CF POWER FEEDTHROUGH, 1000 AMPS, 1 COPPER TUBE CONDUCTOR, WATERCOOLED
261-1000WC-BP
1” BASEPLATE POWER FEEDTHROUGH, 1000 AMPS, 1 COPPER TUBE CONDUCTOR, WATERCOOLED
261-13CU1K
WELDABLE POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 1KV DC, 25A
261-13CU5K
WELDABLE POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 5KV DC, 25A
261-13NI5K
WELDABLE POWER FEEDTHROUGH, NICKEL CONDUCTOR, 1 PIN, 5KV DC, 8A
261-13SS1K
WELDABLE POWER FEEDTHROUGH, STN STL CONDUCTOR, 1 PIN, 1KV, PIN ⌀ 1.3mm
261-13SS5K
WELDABLE POWER FEEDTHROUGH, STN STL CONDUCTOR, 1 PIN, 5KV, PIN ⌀ 1.27mm
261-190CU8K
WELDABLE POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 8KV, 800A, PIN ⌀ 19mm
261-190CU8K-C40
DN40CF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 8KV DC, 800A, PIN ⌀ 19.05mm
261-190CU8K-K40
DN40KF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 8KV DC, 800A, PIN ⌀ 19.05mm
261-198CU3K-BP
1” BASEPLATE POWER FEEDTHROUGH, COPPER, 1 PIN, 8KV DC, 800A, PIN ⌀ 19.05mm
261D-24CU10K
WELDABLE POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 10KV DC, 50A , PIN ⌀ 2.39mm
261-24CU5K
WELDABLE POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 5KV DC, 50A, PIN ⌀ 2.39mm
261-24CU5K-C16
DN16CF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 5KV DC, 50A, PIN ⌀ 2.4mm
261-24CU5K-K16
DN16KF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 5KV DC, 30A, PIN ⌀ 2.4mm
261-40CU5K
WELDABLE POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 5KV DC, 100A, PIN ⌀ 4mm
261-40CU5K-C40
DN40CF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 5KV DC, 100A, PIN ⌀ 3.96mm
261-63CU5K-C16
DN16CF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 5KV DC, 180A, PIN ⌀ 6.35mm
261-63CU5K-K16
DN16KF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 5KV DC, 180A, PIN ⌀ 6.35mm
261-96CU3K
WELDABLE POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 8KV DC, 300A, PIN ⌀ 9.65mm
261-96CU3K-C16
DN16CF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 3KV DC, 300A, PIN ⌀ 9.6mm
261-96CU3K-K16
DN16KF POWER FEEDTHROUGH, COPPER CONDUCTOR, 1 PIN, 3KV DC, 300A, PIN ⌀ 9.6mm
264-08MO500-2-C16
DN16CF POWER FEEDTHROUGH, 2x MOLYBDENUM CONDUCTORS, 8A
264-08MO500-4
WELDABLE POWER FEEDTHROUGH, 4x MOLYBDENUM CONDUCTORS, 8A
264-08MO500-4-C16
DN16CF POWER FEEDTHROUGH, 4x MOLYBDENUM CONDUCTORS, 8A
264-08MO500-8
WELDABLE POWER FEEDTHROUGH, 8x MOLYBDENUM CONDUCTORS, 8A
264-08MO500-8-C16
DN16CF POWER FEEDTHROUGH, 8x MOLYBDENUM CONDUCTORS, 8A
264-13CU1K-2
WELDABLE POWER FEEDTHROUGH, COPPER CONDUCTORS, 2 PINS, 1KV DC, 25A, PIN ⌀ 1.27mm
264-13CU1K-2-BP
1″ BASEPLATE FEEDTHROUGH, 2x COPPER CONDUCTORS, 1 KV, 25A, PIN ⌀ 1.3mm
264-13CU1K-2-C16
DN16CF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 1 KV, 25A, PIN ⌀ 1.3mm
264-13CU1K-2-K16
DN16KF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 1 KV, 25A, PIN ⌀ 1.3mm
264-13CU1K-4
WELDABLE POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, , 1KV DC, 25A
264-13CU1K-4-BP
1”BASEPLATE POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 1KV DC, 25A
264-13CU1K-4-C16
DN16CF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 1KV DC, 25A
264-13CU1K-4-K16
DN16KF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 1KV DC, 25A
264D-13CU1K-8
WELDABLE POWER FEEDTHROUGH, 8x COPPER CONDUCTORS, 1KV DC, 25A
264-13CU1K-8-BP
1”BASEPLATE POWER FEEDTHROUGH, 8x COPPER CONDUCTORS, 1KV DC, 25A
264-13CU1K-8-C16
DN16CF POWER FEEDTHROUGH, 8x COPPER CONDUCTORS, 1KV DC, 25A
264-13CU1K-8-K16
DN16KF POWER FEEDTHROUGH, 8x COPPER CONDUCTORS, 1KV DC, 25A
264-13CU5K-2
WELDABLE POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 5KV, 20A
264-13CU5K-2-C16
DN16CF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 5KV, 20A
264-13CU5K-2-K16
DN16KF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 5KV, 20A
264-13CU5K-4
WELDABLE POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 5KV, 20A
264-13CU5K-4-C16
DN16CF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 5KV, 20A
264-13CU5K-4-K16
DN16KF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 5KV, 20A
264-13KO1K-8-K16
DN16KF POWER FEEDTHROUGH, 8x KOVAR CONDUCTORS, 5KV, 7A
264-13NI5K-2
WELDABLE POWER FEEDTHROUGH, 2x NICKEL CONDUCTORS, 5KV, 7A
264-13NI5K-2-C16
DN16CF POWER FEEDTHROUGH, 2x NICKEL CONDUCTORS, 5KV, 7A
264-13NI5K-2-K16
DN16KF POWER FEEDTHROUGH, 2x NICKEL CONDUCTORS, 5KV, 7A
264-13NI5K-4
WELDABLE POWER FEEDTHROUGH, 4x NICKEL CONDUCTORS, 5KV, 7A
264-13NI5K-4-C16
DN16CF POWER FEEDTHROUGH, 4x NICKEL CONDUCTORS, 5KV, 7A
264-13SS1K-2-C16
DN16CF POWER FEEDTHROUGH, 2x STAINLESS STEEL CONDUCTORS, 1KV, 1A
264-13SS1K-4
WELDABLE POWER FEEDTHROUGH, 2x STAINLESS STEEL CONDUCTORS, 1KV, 1A
264-13SS1K-4-C16
DN16CF POWER FEEDTHROUGH, 4x STAINLESS STEEL CONDUCTORS, 1KV, 1A
264-13SS1K-4-K16
DN16KF POWER FEEDTHROUGH, 4x STAINLESS STEEL CONDUCTORS, 1KV, 1A
264-13SS5K-2
WELDABLE POWER FEEDTHROUGH, 2x STAINLESS STEEL CONDUCTORS, 5KV, 1A
264-13SS5K-4
WELDABLE POWER FEEDTHROUGH, 4x STAINLESS STEEL CONDUCTORS, 5KV, 1A
264-13SS5K-4-C16
DN16CF POWER FEEDTHROUGH, 4x STAINLESS STEEL CONDUCTORS, 5KV, 1A
264-13SS5K-4-K16
DN16KF POWER FEEDTHROUGH, 4x STAINLESS STEEL CONDUCTORS, 5KV, 1A
264-24CU10K-2-C16
DN16CF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 10KV, 30A
264-24CU10K-4-C40
DN40CF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 10KV, 30A
264-24CU10K-4-K40
DN40KF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 10KV, 30A
264-24CU5K-12-C40
DN40CF POWER FEEDTHROUGH, 12x COPPER CONDUCTORS, 5KV, 50A
264-24CU5K-12-K40
DN40KF POWER FEEDTHROUGH, 12x COPPER CONDUCTORS, 5KV, 50A
264-24CU5K-2-C16
DN16CF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 5KV, 50A
264-24CU5K-2-K16
DN16KF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 5KV, 50A
264-24CU5K-4-C40
DN40CF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 5KV, 50A
264-24CU5K-4-K40
DN40KF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 5KV, 50A
264-24CU5K-8-C40
DN40CF POWER FEEDTHROUGH, 8x COPPER CONDUCTORS, 5KV, 50A
264-24CU5K-8-K40
DN40KF POWER FEEDTHROUGH, 8x COPPER CONDUCTORS, 5KV, 50A
264-63CU5K-2-C40
DN40CF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 5KV, 180A
264-63CU5K-2-K40
DN40KF POWER FEEDTHROUGH, 2x COPPER CONDUCTORS, 5KV, 180A
264-63CU5K-3-C40
DN40CF POWER FEEDTHROUGH, 3x COPPER CONDUCTORS, 5KV, 180A
264-63CU5K-4-C40
DN40CF POWER FEEDTHROUGH, 4x COPPER CONDUCTORS, 5KV, 180A
